Low Resistance Shaft Grounding Ring for VFD Industrial Motors Bearing Electrical Erosion Protection

About Product

Highlight

The Volsun shaft grounding ring is precision-engineered from high-performance conductive fibers and a metal ring body, specifically designed to address bearing electrical erosion in variable frequency drive (VFD) motors and coupled equipment. By providing a bypass grounding path, it safely channels shaft currents-generated on the motor shaft-to the ground. This significantly mitigates the risk of electrical erosion, protects motor bearings, and ensures long-term, stable, and reliable motor operation
Protect Electric Motor Bearings: Volsun shaft grounding rings (specifically the VS-RDW series) are high-performance protection devices designed to safeguard motor bearings from electrical corrosion, compatible with VFD systems, supports high-power and high-voltage platforms, with rotational speeds up to 25,000 rpm
Superior Technical Protection Effective Voltage Suppression: They provide a continuous, low-impedance path that diverts harmful high-frequency shaft currents to the ground before they can discharge through the bearings
360-Degree Conductive Fiber Technology: Unlike traditional single-point brushes, Volsun uses a multi-contact conductive fiber structure that ensures stable continuous contact even at high rotational speeds
Design and Versatility Customization and Compatibility: They support a wide range of shaft diameters(from 10mm-300mm) and come in various shapes(round, T-shaped, fan-shaped, etc.) to fit specific OEM or retrofit requirements
Harsh Environment Resilience: Operates reliably from -40°C to 200°C. Resistant to grease, ATF, salt spray, etc
Static resistance < 1Ω; provides a stable, low-impedance bypass path for inverter-generated common-mode currents
Validated under rigorous operating conditions; effectively reduces shaft voltage by over 70%
