High Temperature Electrical Wire Sleeve Acrylic Resin Coated Fiberglass Sleeving

Volsun High Temperature Electrical Wire Sleeve is a reliable, easy-to-use solution for protecting wires and cables in demanding environments. Made from woven fiberglass and coated with a clear acrylic resin, this sleeving combines strong thermal resistance with flexible handling. It resists heat, abrasion, and many chemicals, making it suitable for automotive, industrial, and household electrical applications

The fiberglass core gives the sleeve excellent thermal stability. It can withstand high temperatures without melting, shrinking, or losing its shape, providing long-term protection for insulation and conductors. The acrylic resin coating adds extra strength and helps the sleeve maintain its woven structure while improving abrasion resistance and reducing fraying at cut ends. Together, these materials create a durable cover that performs well where heat and rough conditions are expected

Volsun sleeving is simple to install. It slips easily over bundles of wires, harnesses, hoses, and tubes, and conforms to irregular shapes without bunching or kinking. The flexible nature of the material allows for neat routing through tight spaces and around bends. For added security, the ends can be fixed with heat-shrink tubing, clamps, or adhesive. The sleeving is available in multiple diameters to fit single wires or larger cable groups, giving you options for different project sizes

Safety is a key advantage of Volsun High Temperature Electrical Wire Sleeve. It helps prevent electrical shorts by insulating wires and reducing the risk of contact with sharp edges or hot surfaces. The sleeve’s resistance to flames and high temperatures adds an extra layer of protection in case of overload or component failure. This makes it a good choice for engine compartments, industrial machinery, and other high-heat locations

Maintenance is minimal. The smooth acrylic surface is easy to clean and does not trap dirt or moisture, so the sleeve remains effective over time. Its resistance to many common chemicals and oils means it will continue to protect wiring in environments where exposure is likely

Volsun High Temperature Electrical Wire Sleeve is a practical, cost-effective way to protect critical wiring systems. With strong thermal performance, durable construction, and straightforward installation, it’s designed to keep electrical assemblies safer and more reliable in tough conditions

Product Overview

UL high voltage Silicone rubber fiberglass sleeve

Made of alkali-free glass fiber woven into a tube, coated with silicone rubber on the outer layer of the tube, and then cured. It has high dielectric strength, good flexibility, heat aging resistance, oil resistance, flame retardant, and temperature resistance up to 200 degree. Widely used in circuit insulation protection for new energy vehicles, special vehicles, rail transit,  etc

Features:

1. Operating temperature:-40°C~200°C

2. Environmental standard: RoHS, REACH

3. Color :Nature, White, Black, Red, Yellow, Blue, Green, Orange, other colors are available

4. Flame retardant rating: HB

5. Rated voltage: 1.5KV, 2.5KV, 4.0KV, 7.0KV

Support customization, ODM & OEM available

Click to contact us for free samples

VR

PRODUCT SPECIFICATIONS

Items	Technical Parameters	Reference Standard
Appearance	No glue leakage, cracking, etc	GB/T 7113.1-2014
Coating hydrolysis	No coating displacement, adhesion, etc	GB/T 7113.2
Cold bending test	-40℃，4h，No cracks, coating peeling and delamination	IEC60684
Temperature	-40℃～200℃	UL1441
Flame retardant rating	HB	UL94
Breakdown voltage	Reference standard	GB/T 1408-2016
Heat Resistance	250℃±5, 24h, No droplets, no flow marks, no cracking	JB/T 7093 2015

Dimensions

I. D. mm			Wall thickness mm				Wall Thickness（mm）			Package
Size	Tolerance	1500V	2500V	4000V	7000V	M/Roll
Φ2.0	-0.10～0.25	0.35±0.1	0.40±0.1	0.45±0.1	0.5±0.1	100
Φ3.0	-0.10～0.25	0.35±0.1	0.40±0.1	0.45±0.1	0.5±0.1	100
Φ4.0	-0.10～0.35	0.4±0.1	0.45±0.1	0.50±0.1	0.55±0.1	100
Φ5.0	-0.10～0.35	0.4±0.1	0.45±0.1	0.50±0.1	0.55±0.1	100
Φ6.0	-0.10～0.40	0.45±0.1	0.50±0.1	0.55±0.1	0.60±0.1	100
Φ7.0	-0.10～0.50	0.45±0.1	0.50±0.1	0.55±0.1	0.60±0.1	100
Φ8.0	-0.10～0.50	0.45±0.1	0.50±0.1	0.55±0.1	0.65±0.1	50
Φ9.0	-0.10～0.50	0.45±0.1	0.50±0.1	0.55±0.1	0.65±0.1	50
Φ10.0	-0.20～0.70	0.50±0.15	0.55±0.15	0.65±0.15	0.7±0.15	50
Φ12.0	-0.20～0.70	0.50±0.15	0.55±0.15	0.65±0.15	0.7±0.15	50
Φ13.0	-0.30～0.80	0.55±0.15	0.60±0.15	0.70±0.15	0.75±0.15	50
Φ14.0	-0.30～0.80	0.55±0.15	0.60±0.15	0.70±0.15	0.75±0.15	50
Φ15.0	-0.30～0.80	0.55±0.15	0.60±0.15	0.70±0.15	0.75±0.15	50

We don't list all sizes here, other sizes are available on request

Company Show

Suzhou Volsun Electronics Technology Co., Ltd. was founded in 2006. We keep focusing on the R&D, production and sales in insulation, sealing & protection solutions
Quality is our culture. Volsun has a modern quality management system, which has passed a series of quality system certification such as IATF16949, ISO9001 etc
Up to now, Volsun cooperated with customers from 88 countries, we offer suitable sealing, waterproof solutions for some well-know enterprises in communication, Automobile, Power industry etc

Certifications

Trade terms	FOB, EXW, CIF, DDU, DDP, CFR
Payment terms	T/T, L/C, Negotiable
MOQ	100M
Supply capability	1,000,000 mts per month
Lead time	Usually 2-3 working days
Shipment	Express, Air, Sea
Port	Shanghai, Ningbo, Shenzhen
Sample availability	Yes
Sample time	Usually 1-2 days
Packaging	Normal: Plastic bag & Carton & Pallet Special: Customized packing

Abroad Exhibition

Las Vagas AAPEX

Moscow Expo

Hannover Messe

Packaging and Shipping

FAQ

Q 1. How long is the payment term
A: We accept T/T 50% deposit and 50% balance against B/L or L/C copy at sight, also accept Western Union, VISA and Paypal

Q 2. What is the normal lead time for product orders
A: The average lead time for prototype/first piece is 7~10 days, if tooling is involved, the lead time for production tooling is 10 days, and the average production time after sample approval is 2-3 weeks

Q 3. What is your standard packaging
A: All goods will be packed in cartons and loaded on pallets. Special packing methods are acceptable when needed

Q 4. Can you tell us the monthly production capacity of your products
A: It depends on the model, we produce more than 1500 tons of rubber materials per month

Q 5. What kind of certificates do you have
A1: We have ISO9001:2015, IATF16949:2016, ISO14001:2015, ISO45001:2018 certified
A2: We have various rubber compounds approved by UL, ROHS and REACH

Q6: How to check the quality of bulk order
A1: We provide pre-production samples to all customers before mass production if needed
A3: We accept third-party inspection, such as SGS, TUV, INTERTEK, BV, etc

Q 7: Can you provide customized service
A: Yes, we accept customization and can produce products in different sizes, packaging, colors according to requirements
